Brand:TP Link

TP-Link EAP110 300Mbps Wireless N300 Ceiling Mount Access Point 1x1Gbps RJ45 PoE 1x Console Port 2x4dBi Omni Internal Antenna

59.95 59.95 59.95 AUD

59.95

In Stock
Add to Cart

NWTL-EAP110


TP-Link EAP110 300Mbps Wireless N300 Ceiling Mount Access Point 1x1Gbps RJ45 PoE 1x Console Port 2x4dBi Omni Internal Antenna

EAP Controller Software enables administrators to easily manage hundreds of EAPs

Supports passive PoE for convenient installation up to 100meters

Ceiling mounting design with chassis make it easy to deploy on a wall or ceiling

Captive portal provides one convenient method of authentication for Wi-Fi guests

Multi-SSID divides multiple wireless networks for different users

Enterprise class Wi-Fi security help to decrease network security threats

HARDWARE FEATURES

Interface Fast Ethernet (RJ-45) Port *1(Support Passive PoE)

Button Reset

Power Supply 24VDC / 1A Passive PoE Supply

Power Consumption 7.7W

Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions ( W x D x H ) 7.1 x 7.1 x 1.9 in. (180*180*47.5mm)

Antenna Type Internal 2* 3dBi Omni

Mounting Ceiling /Wall Mounting (Kits included)

Physical Security Lock Kensington Lock Slot

Watch Dog Yes

WIRELESS FEATURES

Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency 2.4-2.4835GHz

Signal Rate 11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Reception Sensitivity 300M: -71dBm@10% PER

150M: -75dBm@10% PER

54M: -78dBm@10% PER

11M: -93dBm@8% PER

6M: -92dBm@10% PER

1M: -96dBm@8% PER

Wireless Functions Multiple SSIDs (Up to 8 SSIDs)

Enable/Disable Wireless Radio

Automatic Channel Assignment

Transmit Power Control (Adjust Transmit Power on dBm)

QoS(WMM)

Rate Limit

Reboot Schedule

Wireless Schedule

Wireless Statistics based on SSID/AP/Client

Wireless Security Captive Portal Authentication

Access Control

Wireless Mac Address Filtering

Wireless Isolation Between Clients

SSID to VLAN Mapping

Rogue AP Detection

802.1X Support

64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

Transmission Power CE:

<20dBm

FCC:

<26dBm

MANAGEMENT

EAP Controller Software Yes

Email Alerts Yes
